100MHz bandwidth, and 1GSa/s real-time sampling rate.
Standard built-in 5MHz signal generator.
8-bit, 12-bit, 14-bit vertical resolution, more accurate measurement.
Max. 10M record length.
Friendly UI, X-Y and waveform can be displayed on the same screen.
Standard SCPI protocol supported, LabVIEW supported.
Secondary development supported on Windows, Linux, Android, and iOS platform.
USB Type-C powered, faster data transmission, support 5-15V wide voltage power supply.
WiFi wireless transmission, more convenient to use. (Need to choose Wi-Fi accessories)
Dual channel 100MHz
Time base auto-range
Cursor readout with 7 measurements
Panel lock function
TV synchronization; X-Y mode
Z-axis modulation input; Trigger signal output
Signal delay function, monitoring the leading edge
Continuously adjustable screen illumination
10 sets memory for panel settings save & recall
70MHz, 100MHz, 150MHz and 200MHz bandwidth
7-inch TFT LCD, WVGA (800*480)
Vertical sensitivity: 1mV/div~20V/div
Time-based range: 2ns/div~50s/div
5,000wfms/s waveform acquisition rate
34 auto measurements
Memory depth 64kpts
USB drive system software upgrade
Standard interface: USB Host, USB Device, Pass/Fail
