POWER
SUPPLY
FROM GW INSTEK
Features:
- 4.3 inch TFT-LCD Display
- Output Capacity: APS-7050E(500VA, 310Vrms, 4.2/ 2.1Arms), APS-7100E(1000VA, 310Vrms, 8.4/ 4.2Arms)
- Only 88mm(2U) case height
- Measurement function comprises Voltage, Current, Power, Current(peak), Frequency, Power Factor
- 10 sets of the Test mode simulate power transient output
- 10 sets of Preset allow users to store ten settings
FROM GW INSTEK
Features:
- Output Rating: AC 0 – 400 Vrms, DC 0 – ± 570 V
- Output Frequency up to 999.9 Hz (ASR-3400HF up to 5000Hz)
- DC Output (100% of Rated Power)
- Measurement Items: Vrms, Vavg, Vpeak, Irms, IpkH, Iavg, Ipeak, P, S, Q, PF, CF
- Voltage and Current Harmonic Analysis(THDv, THDi)
- Remote Sensing Capability
- OCP, OPP, OTP, AC Fail Detection and Fan Fail Alarm
- Support Arbitrary Waveform Function
- Output Capacity: 2kVA/ 3kVA/4kVA
- Customized Phase Angle for Output On/Off
- Sequence and Simulation Function(up to 10 sets)
- Interface(std): USB, LAN, RS-232, GPIB
- Built-in External Control I/O and External Signal Input
- Built-in Output Relay Control
- Memory Function (up to 10 sets)
- Built-in Web Server
FROM GW INSTEK
Features:
- 4.3”TFT LCD Display
- Setting resolution: 1mV / 0.1mA; read back resolution: 0.1mV / 0.1mA
- Low ripple noise: ≦1mVrms/ ≦2mArms
- Transient response time: ≦100µS
- Load function (CC, CV, CR mode)
- Tracking series and parallel function without additional external wiring
- Utilizing hardware to realize over voltage protection / over current protection / over temperature protection
- Delay function / output monitoring function / output recorder function
- Supports setting value, measurement value and output waveform display
- Sequential output function and built-in 8 template waveforms
- The output recorder function records the output voltage & current parameters with a minimum recording interval of 1 second
- Provides 10 sets of memory for each sequence/delay/recorder/panel setting condition
- Supports a USB (Type A) output terminal
- Intelligent temperature control fan effectively reduces noise
- Standard: RS-232, USB, Ext I/O ; Optional(manufacturer installed only): LAN or GPIB+LAN
FROM GW INSTEK
Features:
- Maximum Output: ±210V/±1.05A/22W
- Built-in 4 Sequence Output Modes, up to 2500 Points
- OVP /OTP Protection Function
- 0.012% Basic Measure Accuracy with 6½-digit Resolution
- Variable Sampling Speed
- SDM (Source Delay Measure) Cycle
- 2-, 4-, and 6-wire Remote V-source and Measure Sensing
- Variable Display Digits
- Built-in Limit Function
- Built-in 5 Calculation Functions
- Standard SCPI Command, Provide Interface: RS-232, USBTMC, LAN, GPIB (Optional)
- 4.3″ TFT LCD, Digital Number Keypad
- Built-in RTC Clock
FROM Twintex
Features:
Full range adjustable output: 1~300V, resolution 0.1V
Output frequency: 47-63Hz, 100Hz, 200Hz
Fast output key for 110/220V and 50/60Hz
High accuracy LED display for voltage, current, frequency, active power, power factor
Fast transient response, response time no more than 2ms for 100% load and unload
Multiple protections: OVP, OCP, OTP and OLP
Optional: RS-232/RS-485 interface for PC remote control on output frequency and voltage
Customized specifications and functions acceptable
FROM Twintex
Features:
Output voltage: phase voltage 1~300V, line voltage 1~520V, resolution 0.1V
Output frequency: 45-65Hz adjustable, fixed 50Hz and 60Hz
Fast output key for 110/220V and 50/60Hz
Phase difference: 120°±2°
High accuracy LED display for voltage, current, frequency, active power, power factor
Fast transient response, response time no more than 2ms for 100% load and unload
Multiple protections: OVP, OCP, OTP and OLP
Optional: RS-232/RS-485 interface for PC remote control on output frequency and voltage
Optional: DC0-5V analog input for output control
Customized specifications and functions acceptable
FROM Twintex
Features:
Measurements: V/A/W/VA/VAR/PF/Hz/CF
Large screen LCD display, 4 or 6 parameters displayed simultaneously
True RMS V, A, W
Auto calibration via computer
Data Hold / Range Hold function
High immunity to external noise
CT ratio(1~9999)
RS-232 and RS485 interfaces
FROM Twintex
Features:
Constant voltage and constant current operations, auto CV and CC switch
Low ripple and noise, low temperature drift
Auto Series and Parallel tracking operations
Output ON/OFF control
Preset function, setting of voltage and current with output open circuit
High efficiency, high power density
Over load and reverse polarity protections
Dual-color four digital panel meters
SMD PCB, high quality, high reliability
FROM Twintex
Features:
Two independent adjustable outputs
Constant voltage and constant current operations
Low ripple and noise, low temperature drift
Auto Series and Parallel tracking operations
Output ON/OFF control
Preset voltage and current
High efficiency, high power density
Over load and reverse polarity protections
Dual-color four digital panel meters
