SPECTRUM

ANALYZER

FROM GW INSTEK

Features:

  • Frequency Range: 9kHz ~ 3 GHz
  • 0.025ppm Frequency Stability and 1ppm aging Rate
  • Built-in Preamplifier, 50dB Attenuator, and Sequence Function
  • RBW: 1Hz ~ 1MHz
  • Sensitivity: -149dBm/Hz (@PreAmp on)
  • Built-in AM/FM Demodulation & Analysis
  • Built-in P1dB point, Harmonic, Channel Power, N-dB bandwidth, OCBW, ACPR, SEM, TOI, CNR, CTB, CSO, Noise Marker, Frequency Counter, Time Domain Power, Gated Sweep
  • Built-in Spectrogram, Topographic and Dual-View Display Modes
  • Remote Control Interface: LAN, USB, RS-232
  • Options: Tracking Generator, GPIB Interface

FROM GW INSTEK

Features:

  • Frequency Range: 9kHz ~ 3 GHz
  • 0.025ppm Frequency Stability and 1ppm aging Rate
  • Built-in Preamplifier, 50dB Attenuator, and Sequence Function
  • RBW: 1Hz ~ 1MHz
  • Sensitivity: -149dBm/Hz (@PreAmp on)
  • Built-in AM/FM Demodulation & Analysis
  • Built-in P1dB point, Harmonic, Channel Power, N-dB bandwidth, OCBW, ACPR, SEM, TOI, CNR, CTB, CSO, Noise Marker, Frequency Counter, Time Domain Power, Gated Sweep
  • Built-in Spectrogram, Topographic and Dual-View Display Modes
  • Remote Control Interface: LAN, USB, RS-232
  • Options: Tracking Generator, GPIB Interface

FROM OWON

Features:

  • Frequency Range from 9 kHz up to3.6 GHz

  • -160dBm Displayed Average Noise Level

  • Phase Noise -82dBc/Hz @1Gz and offset at 10KHz

  • Total Amplitude Accuracy <1.5dB

  • 10Hz Minimum Resolution Bandwidth (RBW)

  • Standard GPS receiver

  • EMI Pre-compliance Test Kit

  • Up to 3.6 GHz Tracking Generator Kit

  • 8 inches  IPS touchscreen display, wider viewing angle

  • Li-ion battery, operating life upto 4-6 hours

FROM OWON

Features:

  • –  Frequency range 9kHz – 1.5GHz
  • -160 dBm Displayed Average Noise Level (DANL)
  • Phase noise -80 dBc/Hz @1GHz and offset at 10 kHz
  • Total amplitude accuracy <0.7 dB
  • 1 Hz minimum resolution bandwidth (RBW)
  • EMI pre-compliance test function (free), EMC test software (options)
  • Optional Tracking Generator (can be upgraded to have TG after purchasing)
  • Waterfall plot graphic, modulation signal quality analysis,
       audio demodulation, ect. multiple general and extended
       test functions.
  • Standard Pass/Fail on-site test and alert function
  • Adopt all-digital intermediate frequency technology
  • Multiple interfaces: USB Host, USB Device, LAN,
       earphone interface, HDMI
  • 9-inch LCD, high resolution 1280×800 pixels

FROM OWON

Features:

  • Frequency Range from 9 kHz up to 7.5 GHz
  • -160dBm Displayed Average Noise Level
  • Phase Noise -98dBc/Hz @1Gz and offset at 10KHz
  • Total Amplitude Accuracy <1.5dB
  • 10Hz Minimum Resolution Bandwidth (RBW)
  • EMI Pre-compliance Test Kit, optional EMC test software
  • Standard Pass/Fail on-site test alert ability
  • Up to 7.5 GHz Tracking Generator Kit
  • 10.4 inches display
